Double Belt Glass Sorting Machine Ccd Optical Glass Color Sorter For Green Glass
Glass Sorting Machine Ccd Optical Color Sorter For Amber Mineral Quartz Separation
Working Flow
Raw materials are put into the machine from in-feed hopper on the top, vibrated by vibrating plate and sliding along material belt into the zone of observation in sorting chamber through sensors and background plate. Under the effect of Light source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject hopper and good materials continue to fall into the finished accept hopper
2. Technical Parameters:
| MODEL | WYDB4 |
| Chutes/Channels | 8/512 |
| Throughput(kg/h) | 3000kg/h-4000kg/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 3.5kw |
| Power Voltage | 240V/50Hz or Customized |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | <2.8M3/Min |
| Weight | 1500kg-2210kg |
| Diamension(L*W*H) | 2750*2100*2500mm |
3. CCD Glass Color Sorter Machine Core Parts:
◉ Japanese lens, Toshiba sensors with power of 16 megapixels (5400 CCD) micro-color detection capability
◉ Germany's OSRAM lED
◉ American ALTRA Processor of Japanese SMC Pneumatic Systems
◉ 15-inch NEC monitors
◉ of Vision's production ejectors with lifetime guarantee
◉ equipped with dust absorption system
◉ equipped with artificial intelligence, adjusting the device with the help of AI
◉ scanning capability up to 30,000 times per second, leading to up to three times more performance than other sorters.
Persian Software
◉ software upgrade capability
◉ reducing energy consumption
4. Examples of Color Sorting Examples
6. Real Photo of WYDB4
7. Our Service:
Pre-sales
We will provide detailed solutions for your special requirement and help you know more about our color sorter.
After-Sale Service
We will test your products at your plant, training your staff, set every file for customer to serve all round service,
so as to ensure your machine working under the best situations.
From the date of use machine, we can provide one year free maintenance ( not the reason of vandalism and
something unexpected, excluding delicate fittings) and lifetime maintenance.
Engineers available to service machinery overseas, we also can train technical staff for customers.We provide
lifelong software upgrade services for our customers for free.
8. Packing and Delivery:
Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Why choose US?
1. Over 15years experiences focus on color sorter. We have the strength give better service and price to you.
2. Overseas Service Station: We have service station, cooperate reseller more than 40 countries. We can meet your requirements on testing, installation and after sales service.
3. OEM/ODM is Supported: We have a strong R&G team. We can research and development suitable color sorter for you.
4. Quality Process Assurance: We pass CE, RoHS and ISO quality management system, each process of production are under strictly standard.
5. Shipping Guarantee: We have professional packaging operations team, independent export qualification to ensure product safety and stability to reach customers in the hands.
6. After-sales Service Guarantee: We provide one year warranty and lifetime maintenance. Free home repair during the warranty period (except for human factors or irresistible natural phenomena caused by failure or damage)
7. Sales team: Our professional sales team is fluent in English, Russian, Chinese , Spanish and Japanese. Can communicate better with customers.
